Lador Floodlight: Pedestal Mount
Model#: ULD-50XXX Ratings: IP66 IK08
- A range of square outdoor IP66 floodlight projectors that meets both aesthetic and functional applications.
- This cubic floodlight range is available with 4 different sizes, starting with a small 2.4" square profile, and increases proportionately to 3", 4.5" and 5.5" square.
- This glare-free luminaire is available in Narrow 10° beam, Medium 19°, Wide 33°, Very Wide 71° and Elliptical 41°x14° beam patterns.
- Engineered to meet harsh outdoor environments, as well as being able to be used as a decorative indoor product.
- Provided with an integral driver and has accessories that include; dichroic color filters, linear spread lens, honeycomb louvres and anti-glare visors.
- This floodlight has a unique aiming and locking system for precise mounting and beam aiming.
- The Lador product family consists of; floodlights, wall sconces, ceiling mounted squares and cluster column event poles.
- Available with a natatorium rated coating.
Other Fixtures in the Lador Design Family:
Spec Sheets and Downloads for Lador Floodlight: Pedestal Mount
Specification Sheets
|
Lador Floodlight
|
| Model No. |
Watts
|
Lumens
|
Kelvin
|
Beam
|
Dimmable 1-10V
|
| Lador 1 |  |
||||
| ULD-50081 | 3 |
222 lm
|
27K,30K,35K,40K, •
|
10°-19°-33°-71°-41°x14°
|
|
|
Lador 2 |
 |
||||
|
11
|
904 lm
|
27K,30K,35K,40K
|
10°-19°-33°-71°-41°x14°
|
||
| Lador 3 |  |
||||
| ULD-50101 |
21
|
1975 lm
|
27K,30K,35K,40K
|
10°-19°-33°-71°-41°x14°
|
• |
| Lador 4 |  |
||||
| ULD-50111 |
39
|
3568 lm
|
27K,30K,35K,40K, •
|
10°-19°-33°-71°-41°x14°
|
•
|
• = Amber LED
Photometric and Downloads
| Product Information |
| Lador Photometric IES |
| Lador - CAD (2D) |
| Lador - IFC |
| Lador - ULD |
