Steamer Street & Area Light, IDA: Horizontal non-adjustable
Model#: USE-900XX Ratings: IP66 Class II F CE IK08 ETL IDA
A slim wedge shaped, high pressure die-cast pole mounted area light with a variety of different light distributions to suit all lighting designer's requirements. This luminaire has been designed to provide excellent light distribution patterns using highly efficient LED packages and optics. The result is excellent spacing to mounting height ratios, with a uniform lighting layout that meets code requirements using less energy.The Steamer can be utilized to suit specific light patterns using the asymmetrical type II, III, IV and symmetrical lens optics, as well as variations of these for precise light distribution requirements. An example of this is using a combination of Type II & Type IV distribution optics inside the same fixture. Type V distributions in medium, wide, very wide & extra wide are also available. This luminaire complies to dark sky requirements when mounted in the horizontal position.Designed for lighting private roadways, car parks, exhibition areas, service stations and truck stops. Internal house side shields are available as an option.Available with a selection of integral electronic and dimmable electronic drivers as well as a provision to install occupancy sensors, as well as wireless lighting controls to integrate with building management systems. (WATT-ADJUST) This luminaire is provided with a programmable driver so that specific wattage requirements can be achieved. These settings are done at the factory during assembly.
Other Fixtures in the Steamer Design Family:
Spec Sheets and Downloads for Steamer Street & Area Light, IDA: Horizontal non-adjustable
Specification Sheets
Steamer Medium Rectangular Head Street & Area Light
|
Model No. |
Lamp
|
Light Output
|
LED Color
|
Power W
|
Dimmable 1-10V
|
USE-90002 |
LED
|
2899 - 13401 lm
|
27K,30K,35K,40K
|
29,50,80,105w
|
•
|
Steamer Large Rectangular Head Street & Area Light
|
Model No. |
Lamp
|
Light Output
|
LED Color
|
Power W
|
Dimmable 1-10V
|
USE-90012 |
LED
|
2954 - 27111 lm
|
27K,30K,35K,40K
|
29,80,120,157,209w
|
•
|
Steamer Medium Round Head Street & Area Light
|
Model No. |
Lamp
|
Light Output
|
LED Color
|
Power W
|
Dimmable 1-10V
|
USE-90022 |
LED
|
2899 - 13401 lm
|
27K,30K,35K,40K
|
29,50,80,105w
|
•
|
Steamer Large Round Head Street & Area Light
|
Model No. |
Lamp
|
Light Output
|
LED Color
|
Power W
|
Dimmable 1-10V
|
USE-90032 |
LED
|
2954 - 27111 lm
|
27K,30K,35K,40K
|
29,80,120,157,209w
|
•
|
Photometric and Downloads
Product Information |
Steamer Photometric IES |
Steamer CAD Files (2D / RFA / 3DS) |
IFC - BIM |
Dialux Files .uld |
