Benton Round Light Column
Model#: UBE-200XX Ratings: IP65 CE IK08 ETL IDA

- A stylish Dark Sky Compliant round high performance light column with downward light distribution using LED lamps.
- This light column offers optimal visual comfort through glare control by utilizing a controlled optics designed by Ligman.
- These light columns have a round design providing a unique wide light distribution, offering an architecturally appealing clover leaf pattern on the paving.
- The internal sides of the supporting pillars are accented by light from the LED.
- Color temperature 2700K, 3000K and 4000K.
- The minimalistic shape provides distinctive lighting effects by night and decorative urban effect during the day.
- Suitable for pedestrian areas, precincts, building surrounds, shopping centers, squares and parks.
- The Benton Light Column comes standard with a unique waterproof internal driver housing compartment that is situated at the top of the pole to stop water and dust from entering the electrical components.
- This fixture is supplied completely wired with power cord and waterproof gland from the driver enclosure to the base of the column to ensure quick trouble-free installation.
- Custom column heights are available, please specify.
- Provided with anchor bolts.
Other Fixtures in the Benton Design Family:
Spec Sheets and Downloads for Benton Round Light Column
Specification Sheets
| Benton Light Column 8.8" | ||||
| Model No. | Watts | Lumens | Kelvin | Dimmable 1-10V |
| UBE-20001 |
40
|
2489 lm |
27K,30K,35K,40K
|
•
|
| Benton Light Column 6.3" | ||||
| Model No. | Watts | Lumens | Kelvin | Dimmable 1-10V |
| UBE-20011 |
20
|
1102 lm
|
27K,30K,35K,40K
|
•
|
|
Benton Light Column With Floodlights
|
| Model No. |
Watts
|
Lumens
|
Kelvin
|
Dimmable 1-10V
|
| UBE-20021 (1 Floodlight) |
40+21
|
2489+1673
|
27K,30K,35K,40K
|
•
|
| UBE-20022 (2 Floodlights) |
40+2x21
|
2489+2x1673
|
27K,30K,35K,40K
|
• |
| UBE-20023 (3 Floodlights) |
40+3x21
|
2489+3x1673
|
27K,30K,35K,40K | • |
Photometric and Downloads
| Product Information |
| Benton Photometric IES |
| Benton CAD Files (2D / RFA / 3DS) |
| IFC - BIM |
| Dialux Files .uld |
